Supply original MMBZ27VAWT1G, TVS - Diodes, by ON Semiconductor

TVS DIODE 22V 40V SC70-3

RoHS
Datasheet
Supply original MMBZ27VAWT1G, TVS - Diodes, by ON Semiconductor | TrustCompo

Pictures are for reference only. Please contact us for the latest pictures.

Part Number

MMBZ27VAWT1G

Internal code

TCE000060500

Package

SC70-3

Manufacturer

ON Semiconductor

Key specifications

Serise

-

Min Quantity

1

Category

Circuit Protection

Sub Categroy

TVS - Diodes

Description

TVS DIODE 22V 40V SC70-3

key Attributes

-

View datasheet

Technical document

Open The Official Datasheet

Review the latest datasheet for MMBZ27VAWT1G from ON Semiconductor in a separate tab so engineers and buyers can check package, electrical characteristics, and application details without leaving this product page.

View datasheet

Why request a quote

Use the RFQ step to confirm the commercial and documentation details buyers usually need before placing an order.

Confirm stock and lead-time expectations
Check CoC or traceability support
Align inspection and fulfillment details

Trust signals

Globally recognized certifications

4 certifications

Visible certifications work best when they are paired with clear operational promises around traceability, handling, and inspection.

ISO 9001

Quality management processes for more consistent sourcing and handling.

AS9120B

Aerospace-focused distribution controls for traceability and reliability.

ISO 14001

Environmental management discipline across warehouse and operating workflows.

ESD Control

Electrostatic handling standards to help protect sensitive components.

Authenticity Verification

CoC Available on Request

Pre-Shipment Inspection

Responsive RFQ Support

Why buyers trust this sourcing flow

Our quality workflow is designed to reduce counterfeit risk and support confident procurement. Components are reviewed through documented handling and inspection steps so buyers can evaluate sourcing with stronger authenticity controls.

Structured product content

Review The Product The Way Buyers Actually Evaluate It

Jump between overview, specs, and related sourcing content without scanning one long uninterrupted page.

Product overview

Overview

TVS DIODE 22V 40V SC70-3

Full technical breakdown

Detailed Specifications

Review grouped attributes and parameters without scanning one oversized table.

Fast scan

Popular Specs Surfaced First

Product Parameter

Terminal Finish

Tin (Sn)

Product Parameter

Number Of Elements

2

Product Parameter

Diode Element Material

SILICON

Product Parameter

Power Line Protection

No

Product Parameter

Test Current

1mA

Product Parameter

Unidirectional Channels

2

Terminal Finish
Tin (Sn)
Number Of Elements
2
Diode Element Material
SILICON
Power Line Protection
No
Test Current
1mA
Unidirectional Channels
2
Max Surge Current
1A
Peak Pulse Current
1A
Number Of Unidirectional Channels
2
Peak Pulse Power
40W
Max Reverse Leakage Current
50nA
Leakage Current
50nA
Max Breakdown Voltage
28.35V
Reverse Standoff Voltage
22V
Voltage - Clamping (Max) @ Ipp
40V
Clamping Voltage
40V
Breakdown Voltage
25.65V
Part Status
Active
REACH Status
REACH Unaffected
ECCN
EAR99
Lead Free
Lead Free
Lifecycle Status
ACTIVE (Last Updated: 2 days ago)
Mounting Type
Surface Mount
Factory Lead Time
16 Weeks
Packaging
Tape & Reel (TR)
Published
2010
Termination
SMD/SMT
Width
1.35mm
Terminal Position
DUAL
Terminal Form
GULL WING
Manufacturer
ON Semiconductor
Categories
Circuit Protection
Type
Zener
Sub-Categories
TVS - Diodes
Subcategory
Transient Suppressors
Operating Temperature
-55°C~150°C TJ
Direction
Unidirectional
Element Configuration
Common Anode
Additional Feature
UL RECOGNIZED
Surface Mount
YES
Pbfree Code
yes
Number Of Pins
3
Pin Count
3
Number Of Terminations
3
ESD Protection
Yes
Applications
General Purpose
Height
900μm
Max Power Dissipation
200mW
Operating Supply Voltage
22V
Depth
1.24mm
Package / Case
SC-70, SOT-323
Length
2.1mm
Base Part Number
MMBZ*V
Bidirectional Channels
1
Working Voltage
22V
Manufacturer'S Part No.
MMBZ27VAWT1G
JESD-609 Code
e3
Moisture Sensitivity Level (MSL)
1 (Unlimited)
RoHS Status
ROHS3 Compliant
REACH SVHC
No SVHC
HTSUS
8541.10.0080
ECCN Code
EAR99
