BAS21LT1G Datasheet PDF
Read the manufacturer datasheet for BAS21LT1G by ON Semiconductor. Search the PDF, review the main part details, and request pricing for this Diodes - Rectifiers - Single component without leaving the page.
Manufacturer datasheetON Semiconductor
Request pricing
Need pricing, availability, or lead time for this part? Send a quote request while reviewing the datasheet.
Technical summary
Key document context
BAS21LT1G from ON Semiconductor is a Diodes - Rectifiers - Single device in SOT23 package. Use this manufacturer datasheet to review its electrical, mechanical, and ordering information.
Voltage - Forward (Vf) (Max) @ If
1.25V @ 200mA
Operating Temperature - Junction
-55°C~150°C
Speed
Small Signal =< 200mA (Io), Any Speed
Use the BAS21LT1G datasheet from ON Semiconductor to verify the ratings, package details, operating limits, and ordering information that apply to your design or sourcing decision.
